Ultraflex UC132-OBS Hydraulic Cylinder Stern Drive Side Mount Unbalanced
Sale

Ultraflex UC132-OBS Hydraulic Cylinder Stern Drive Side Mount Unbalanced

Ultraflex
SKU:
JPW18918
$867.47 $828.04
$867.47
(You save $39.43 )
(No reviews yet)
Current Stock:
2
Adding to cart… The item has been added
Description
  • For outboard engines up to 300HP
  • Unbalanced: the number of turns lock-to-lock is not equal port to starboard and vice versa
  • UC132-OBS side mount cylinder features a patented turning nut for a fast and easy installation to the engine tube
  • Clearance required at the engine tube side is 375mm
  • Recommended use for where maximum boat speed does not exceed 40 knots
  • The UC132 cylinders are recommended for use with UP25, UP28, UP33 series helms and pre-assembled hoses
  • 9.5mm Fittings: For high pressure flex hose

Note: UC132-OBS cylinder is not intended for use with 105 Bar (1500psi) SilverSteer Series Helms

Warning: This application requires that the threads on the tilt tube extend at least 15mm from both sides



Type Volume Output
Force		 Inside
Diameter		 Stroke
UC132-OBS Outboard 132/163cc 464/574kg 32mm 203mm
