Swage Terminals - Stainless Steel
RWB Marine
$3.50 - $13.50
(No reviews yet)
Write a Review
RWB Marine
Swage Terminals - Stainless Steel
316 grade stainless steel whitworth threaded swage stud terminals. Suits imperial size wire rope.
| Size | D1 (Thread) | D2 (Wire) | L1 | L2 | L3 | Uni Die |
|---|---|---|---|---|---|---|
| 3/16" x 3/32" | 3/16" | 3/32" (2.4mm) | 72mm | 30mm | 30mm | 3 |
| 3/16" x 1/8" | 3/16" | 1/8" (3.2mm) | 90mm | 36mm | 40mm | 4 |
| 1/4" x 5/32" | 1/4" | 5/32" (4mm) | 108mm | 42mm | 50mm | 5 |
| 5/16" x 3/16" | 5/16" | 3/16" (4.8mm) | 115mm | 52mm | 50mm | 6 |
| 3/8" x 1/4" | 3/8" | 1/4" (6.4mm) | 157mm | 63mm | 75mm | 8 |
