Quick GP2 1200 Horizontal On-Deck Windlass
Quick
$2,230.31
(No reviews yet)
Write a Review
Quick
Quick GP2 1200 Horizontal On-Deck Windlass
A compact, on-deck mounted windlass providing functionality and efficiency. Manufactured for the harsh marine environment, the Genius GP2 1200 features a robust anodised marine grade alloy housing and a 316 grade stainless steel gypsy.
Recommended Boat Size: 6m - 9m (20ft - 30ft)
Manufactured for the harsh marine environment, the Genius GP2 1200 features a robust anodised marine grade alloy housing and a 316 grade stainless steel gypsy.
The Genius GP2 1200F free fall version allows fast, precision anchoring.
Quick's patented free fall mechanism will send the anchor into free fall from the touch of a button, when hitting that ledge or wreck, really matters. The serious fisherman's friend!
Features:
- GP2 1200: Power Up / Power Down operation
- GP2 1200FF: Quick's Free Fall technology
- Ideal for restricted above deck mounting
- Anodised alloy housing for reduced corrosion
- Dual direction permanent magnet motor for greater output and reduced power consumption
- Made in Italy
- 3 year warranty from the date of sale
Standard Inclusions:
- Composite Clutch Manual Release Handle
- Isolator/Circuit Breaker Panel
- Reversing Solenoid
- Gypsy: to suit 6-8mm short link chain, 12mm three-strand nylon or polyester rope
Optional Additions:
- Foot Switches: Up-Down for the deck
- Digital Chain Counters
- Hand Held Remote Controls
- Remote Up/Down Panel Switch
| Model | GP2 1200 | GP2 1200FF |
|---|---|---|
| Watts | 250 watts | 250 watts |
| Volts | 12 volts | 12 volts |
| Amps | 35 amps | 35 amps |
| Chain Standard (Opt.) | 6 (8mm) | 6 (8mm) |
| Rope Size | 12mm | 12mm |
| Maximum Pull | 550kg | 550kg |
| Maximum Working Load | 170kg | 170kg |
| Maximum Chain Speed | 31.2m/min | 31.2m/min |
| Drive Shaft | Horizontal | Horizontal |
| Capstan Option | No | No |
| Chain/Rope Gypsy | Yes | Yes |
| Dimensions (mm) | 213 (L) x 184 (W) x 129 (H) | |
| Weight | 8kg | 8kg |
