High quality, Australian made, white nylon skin fittings with a tapered outer head to lower drag.
They have a connection with a barbed tail for hose on one end and a BSP male thread on the other.
The barbed tail can be cut off if threaded male connection is to screw into valve.
Note: JPW1801 features a dual sized barbed tail.
| JPW SKU | Hose Size | Mount Hole (mm) |
Thread Length (mm) |
Overall Length (mm) |
|
|---|---|---|---|---|---|
| inches | mm | ||||
| JPW1801 | Dual: 1/2 & 5/8 | Dual: 13 & 16 | 20 | 30 | 73 |
| JPW1802 | 3/4 | 19 | 25 | 52 | 95 |
| JPW1803 | 1 | 25 | 32 | 52 | 95 |
| JPW1804 | 1 1/4 | 32 | 40 | 52 | 98 |
| JPW1805 | 1 1/2 | 38 | 46 | 52 | 95 |
| JPW1806 | 1 1/8 | 28 | 32 | 52 | 95 |
