Narva LED 4-Way Switch Panel with Fuse or Circuit Breaker Protection

Narva LED 4-Way Switch Panel with Fuse or Circuit Breaker Protection

NARVA
$175.00 - $210.00
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Ideal for boat, mobile home or caravan applications, these switch panels are pre-wired and feature concealed electrical protection. Choose from either blade fuse or manual reset circuit breaker protection, both easily serviced via the removable cover.

Each panel can be mounted horizontally or vertically to best suit the application and are supplied with a sticker set with popular RV and Marine symbols.

These LED Rocker switch panels are suitable for either 12 or 24 volt operation.

Fuse Protection panel features:

  • 4x On/Off switches with red 'On' illumination
  • 46 piece symbol set for RV and marine applications

Circuit Breaker panel features:

  • 3x On/Off switches and 1x Momentary (On) switch
  • Circuit Breakers: 2 x 10A, 2 x 15A
  • Symbols and switches illuminate GREEN when 'ON'
  • Symbols illuminates RED when 'OFF'
  • 60 piece symbol set for RV and marine applications
  • Fuse and circuit breaker concealed under face cover



Description Amperage Rating Mounting Opening Overall Size
Fuse Protection 20A @ 12V / 10A @ 24V 105 x 93mm 130 x 120mm
Circuit Breaker Protection 20A @ 12V / 10A @ 24V 108 x 83mm 130 x 100mm
